Forming and sealing speed   12-40cartons/min
A bottle loading machine having a bottle transfer conveyor transferring charges of bottles in aligned rows to a case loading station for being deposited through a grid set into a case carried there below. Aligned pairs of gripping arms are carried in the path of the transfer conveyor directly over the grid set for receiving the aligned rows of bottles. A pair of abutments are carried adjacent the forward end of the grid set for tilting the leading bottle of the charge of bottles so that when the bottles are dropped, they drop freely into the case. A plurality of stops are carried on a pivotal arm positioned adjacent the junction of the transfer conveyor and the grid set for restraining the incoming bottles as the charge is being dropped into the case.
Carton size: (30 7 * 19 * 21 6) mm We have drawn up a loaded boxes (15 bottles / box ,500ml / bottle) shall prevail. Other bottle types and  carton size for special design.
   bottle size： provied drawing of bottle
   Layer patterns required：   2*3、4*6、3*5、3*4  either one or two patterns formation
   packing speed：  10-15  cartons/ min
   Packaging Range:Applied to small-bottle production line type of all types of bottles
   machine net weight： 2000Kgs
   power：  380V/  50Hz / 3ph
   compressed air consumption;  <0.9m3 /min
   either one or two patterns format
