● Fully automatic adjustment on height and width for various size carton..
● Side belts driven.

Standard Specification
Model       RPE-05
Carton size      (L)200-(W)200-500(H)200-500mm
Table height     680(min.) ~ 780mm(max.)
Working speed     300-750ctns/hr
Machine size      (L)1170(W)880(H)1150
Power       110V/220V single phase,
50/60Hz or specified by client
Pneumatic      5kg/cm2
Tape width      48mm, 75mm(alternative use)
Machine net weight   approx. 180kgs
