● Fit for stapling various size carton in mass production line.
● Automatic flaps folding and, top and bottom stapling.
● Side belts driven, suitable for heavy duty operation.
● Easy to operate.

Standard Specification
Model       RPJ-03R
Carton size      (L)200-500(W)200-500(H)200-500mm
Table height     650(min.) ~ 800mm(max.)
Stapling speed         4-6ctns/min
Machine size      (L)1700(W)850(H)1400mm
Power       110V/220V single phase,
50/60Hz or specified by client
Pneumatic      5kg/cm2  250L/min
Carton sealer pin    3315/3318
Machine net weight   approx. 230kgs
